Quick Details

  • Condition: New
  • CNC or Not: CNC
  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: Fundar
  • Model Number: 6090 3axis
  • Voltage: 220V/110V
  • Power(W): 1500W / 2200W
  • Dimension(L*W*H): 860*630*480mm
  • Weight: 60KG (Machine net weight)
  • Certification: CE
  • Warranty: 3 Years
  • After-sales Service Provided: Engineers available to service machinery overseas
  • 3 axis cnc 6090 X,Y,Z Working Area: 600mm*900mm*150mm
  • Max. Feeding height: 150mm
  • Table size: 600mm*900mm
  • Acceptable material thickness: 150mm
  • Stepping motor type: 57 two-phase 3A 150N.cm
  • Spindle motor: brand new 2.2KW water cooling spindle, 24000RPM
  • Principal axis collet: ER11/3.175 mm/6mm
  • Repeat accuracy: 0.05mm
  • Spindle precision: radial beat acuities 0.03 mm
  • Computer connection: DSP systerm, no need to use computer

Packaging & Delivery

Packaging Details Wooden case
Weight:150kg
Delivery Time 3-5 days after payment

CNC router machine 6090 with dsp controller systerm

Product Description



Don't need connect Computer ,G-code in Micro sd card ,plug in controller box



This CNC router machine 6090 with dsp controller systerm can be widely used
A. Widely used not only for Aluminum but also acrylic, brass, wood, PVC, PCB, MDF and so on.
B. Ideal for milling, engraving, drilling & routing.
C. For Industry, Technology Research, Advertising Design, Arts Creation, Teaching, Student Project and Hobby Purposes, Building Model Making, Advertising Signs, Artwork, Crafts,Aircraft Models, RC Model parts

Highlights



      *   Independent DSP system, work without a computer.
      *   Insert TF memory card, automatic reading and processing files.
      *   By operating the control box, you can program and carving directly.
      *   G-code files can be directly edited, delete, insert, and so on



Easy operating because:


      *  With DSP controller box, no need to connect with any computer or notebook.
      *  Work independently.
      *  SD card slot interfaceWith SD card slot interface.
      *  2.2KG water-cooled spindle, powerfu!
      *  Fast working speed.
      *  Live video support on Youtube.


Other main featurers of this 6090 CNC router machine with dsp controller systerm


      *  English manual available.
      *  Can engrave material such acrylic, brass, wood, aluminum, PCB and so on.
      *  Balls crew made it a higher precision.
      *  4th axis can be plug-and-play, no need to replace controller box.
      *  Auto-Checking function, easy to set origin of Z axis.
      *  With built-in frequency converter in control box.
      *  It has a broad-base and a thicker screw for larger material working.
      *  Limited switches added.
      *  From reliable & trustable profesional China CNC Router factory.



Detail images



Specifications



Shape dimension

X860mm*Y630mm*Z480mm

Max.workpiece dimension

X600mm*Y900mm*Z150mm

Frame materials

aluminum alloy 6063 and 6061 the unique and dedicated mold extrusion profiles. let  counterfeiters dwarfs

Acceptable material thickness

≤150mm

Driving units

X:  1605 ball screw

Y:  2005 ball screw

Z:  1605 ball screw

Sliding units

X:  Dia.30mm chrome plate shafts

Y:  Dia.30mm chrome plate shafts

Z:  Dia.16mm chrome plate shafts

Stepping motor type

57-76 two-phase 3A 150N.cm

Spindle motor

brand new 2.2kw water cooling spindle, 24000RPM

Spindle collet

ER16-A, 3-10 mm shank diameter tool

Repeat accuracy

<=0.05mm

Spindle precision

Radial beat acuities 0.03 mm

Carving Instructions

G code/ TAB files/ nc file/ NCC files

Maximum speed

4000mm/min

Carving speed

0-2500mm/min (different materials differ)

Command code

G code

Protection

Emergency stop button

Operating Voltage

AC110V/AC220V

The 4th axis

Size

136*116*92 mm

Centre-height

34mm

Clamping diameter

50mm fingertight fitting

Reduction tatio

1:03

Error Range

0.1



Packaging list
1 Engraving machine
1 Rotary axis
1 Controller box with invertor installed in it
1 1500w / 2200w spindle
1 Power cable
1 Water pump
4 Engraving bit
2 Limited switch
1 Auto-checking tool
1 set of clamp tool
